3 WLAN Mode
3.6 Modulation Analysis Measurement
Remote Command
:CALCulate:EVM:MAXPower:MCS7 <rel_ampl>
:CALCulate:EVM:MAXPower:MCS7?
Example
:CALC:EVM:MAXP:MCS7 -10
:CALC:EVM:MAXP:MCS7?
Notes Only available for 11ax/be
Preset -10dBm
State Saved Saved in instrument state
Min -200
Max 100
Backwards Compatibility
SCPI
:CALCulate:EVM:AX:MAXPower:MCS7 <rel_ampl>
:CALCulate:EVM:AX:MAXPower:MCS7?
3.6.8.9 Advanced
Contains controls for setting advanced function s of the analyzer.
Dependencies This tab does not appear in EXM E6640A or VXT models
M9420A/M9421A/M9410A/M9411A/M9415A/16A
PhNoise Opt
Allows you to select the LO (local oscillator) phase noise behavior for various
operating conditions
Remote Command
[:SENSe]:EVM:FREQuency:SYNThesis[:STATe] 1 | … | 5
For the meaning of each numeric option value, see "Parameter Options & Installed Options" on page
1065 below
[:SENSe]:EVM:FREQuency:SYNThesis[:STATe]?
Example
:EVM:FREQ:SYNT 1
:EVM:FREQ:SYNT?
Dependencies This control does not appear in UXM E7515A, Modular PXI Signal Analyzer M9393A or M9391A
Preset 3
State Saved Saved in instrument state
Range See "Ranges" on page 1070
Parameter Options & Installed Options
The Phase Noise Optimization control lets you optimize the setup and behavior of
the Local Oscillator (LO) depending on your specific measurement conditions. You
may wish to trade off noise and speed, for example, to make a measurement faster
