Keysight M9421A - Average Type

3 WLAN Mode
3.12 IQ Waveform Measurement
–
EXPonential, The measurement averaging continues using the specified
number of averages to compute each averaged value. The average is displayed
at the end of each sweep
–
REPeat: The measurement resets the average counter each time the specified
number of averages is reached
Remote
Command
[:SENSe]:WAVeform:AVERage:TCONtrol EXPonential | REPeat
[:SENSe]:WAVeform:AVERage:TCONtrol?
Example
:WAV:AVER:TCON REP
:WAV:AVER:TCON?
Preset
EXPonential
State Saved Saved in instrument state
Range
EXPonential|REPeat
Average Type
Sets the type of averaging. When AUTO is selected, the instrument chooses the type
of averaging. Available Average Types are:
Option Parameter
Log-Pwr Avg
LOG
Power (RMS)
RMS
Voltage
SCALar
When one of the average types is selected manually, the instrument uses that type
regardless of other instrument settings, and shows Man on the Average Type
control.
Remote
Command
[:SENSe]:WAVeform:AVERage:TYPE LOG | MAXimum | MINimum | RMS | SCALar
[:SENSe]:WAVeform:AVERage:TYPE?
For EXT-C, E6630A, E6640A, M90XA, use the following command
[:SENSe]:WAVeform:AVERage:TYPE LOG | RMS | SCALar
Example
:WAV:AVER:TYPE RMS
:WAV:AVER:TYPE?
Notes The selections MAX and MIN are retained for backwards compatibility, but they are removed from the
front panel access because they are not an Average function
Couplings AUTO selects Power (RMS) averaging if a Marker Function (Marker Noise, Band/Intvl Power) is on
Preset
RMS
State Saved Saved in instrument state
Range Log-Pwr Avg | Power (RMS) | Voltage
Auto Function
