3 WLAN Mode
3.12 IQ Waveform Measurement
Valid Measurement Keywords
This function is available only in certain Modes and measurements. Only the
following listed values of <meas> are valid.
Mode(s) Meas
<meas>
BASIC
Complex Spectrum
SPECtrum
BASIC
CQM
EDGEGSM
LTEAFDD
LTEATDD
MSR
NR5G
PNOISE
SRCOMMS
VMA
WCDMA
WLAN
IQ Waveform
WAVeform
WLAN
Modulation Analysis
EVM
WLAN
MIMO Modulation Analysis
EVMMimo
Optimize EVM
This is an "immediate action" function to optimize IQ data capture settings for best
EVM. It is used to set the combination of preamp, mechanical and electronic
attenuation and IF gain value based on measured signal peak level. Its purpose is to
get better EVM results by improving SNR and avoid ADC overload at the same time.
After this control is pressed, Pre-Adjust for Min Clipping changes to OFF and IF Gain
Auto changes to Manual.
Remote Command
[:SENSe]:WAVeform:OPTimize:EVM
Example
:WAV:OPT:EVM
Mixing Mode State (Remote Command Only)
Available only in the Complex Spectrum, Streaming, and Waveform measurements.
1849 WLAN Mode User's &Programmer's Reference
