3 WLAN Mode
3.3 Occupied BW Measurement
This setting affects sensitivity and IF overloads. It only applies to the RF input; not to
the baseband I/Q input.
Remote Command
[:SENSe]:OBWidth:IF:GAIN[:STATe] ON | OFF | 1 | 0
[:SENSe]:OBWidth:IF:GAIN[:STATe]?
[:SENSe]:OBWidth:IF:GAIN:AUTO[:STATe] ON | OFF | 1 | 0
[:SENSe]:OBWidth:IF:GAIN:AUTO[:STATe]?
Example
:OBW:IF:GAIN ON
:OBW:IF:GAIN?
:OBW:IF:GAIN:AUTO OFF
:OBW:IF:GAIN:AUTO?
Dependencies Has no effect when the U7227A USB Preamplifier is connected. This is not annotated or reflected on
any control; there are no controls grayed-out nor any SCPI locked out. The instrument simply behaves
as though both IF Gain is set to Low regardless of the setting on the control
Not available in VXT models M9420A/10A/11A, EXM, or UXM
Couplings Auto sets IF Gain to High (ON) under any of the following conditions:
–
The input attenuator is set to 0 dB, or
–
The preamp is turned on and the frequency range is under 3.6GHz
For other conditions, Auto sets IF Gain to Low (OFF)
Preset
OFF
OFF
State Saved Saved in instrument state
Range Low Gain | High Gain
3.3.8.5 Global
The controls in this menu apply to all Modes in the instrument.
Some controls (for example, "Global Center Freq" on page 1850) allow you to switch
certain Meas Global parameters to a Mode Global state. These switches apply to all
Modes that support global settings. For example, no matter what Mode you are in
when you set Global Center Freq to ON, it applies to all Modes that support Global
settings.
Other controls (for example, Extend Low Band) are actually set in this menu, but
apply to all Modes.
Global Center Freq
The software maintains a Mode Global value called Global Center Freq.
421 WLAN Mode User's &Programmer's Reference
