3 WLAN Mode
3.6 Modulation Analysis Measurement
M941xE-B4X = 400.0 MHz
M941xE-B8X = 800.0 MHz
M941xE-B12 = 1.2 GHz
M941xAU-B6X = Upgrade from 400.0 MHz to 800.0 MHz
M941xAU-B12 = Upgrade from 400.0 MHz to 1.2 GHz
M941xAU-BU2 = Upgrade from 800.0 MHz to 1.2 GHz
All other models:
B1Y=160 MHz, B1X=140 MHz, B1A=125 MHz, B85= 85 MHz, B40=40 MHz, B25=25 MHz, else 10
MHz
When Info BW auto coupled by Radio Std exceeds max BW of hardware, there will be an error
message: “Invalid result; Wider BW required”
If BW is less than Radio Std default value, there will be a conditional warning message: “Setting Alert;
BW is less than xxx”
Backwards
Compatibility SCPI
[:SENSe]:<meas>:BWIDth[:RESolution]
3.6.5 Display
Opens the Display menu, which lets you configure display items for the current
Mode, Measurement View or Window.
3.6.5.1 Meas Display
Contains controls for setting the display for the current window.
I/Q Polar Vec/Constln
Specifies the format of the Polar Vector graph display. You can select one of the
following formats:
–
Vec Constln (Vector and Constellation)
–
Vector (Vector only)
–
Constellation (Constellation only)
This function is available for I/Q Measured Polar window when Radio Standard is
802.11a/g/j/p (OFDM), 801.11g (DSSS-OFDM), or 802.11n/ac/ah/ax/be.
Remote
Command
:DISPlay:EVM:VIEW[1]:WINDow[1]:TRACe:POLar VC | VECTor | CONStln
:DISPlay:EVM:VIEW[1]:WINDow[1]:TRACe:POLar?
Example
:DISP:EVM:VIEW:WIND:TRAC:POL CONS
WLAN Mode User's &Programmer's Reference 938
