Keysight M9421A - Scale;Div

3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Group Result Min Max Unit
Terminat
or
Default Knob
Increme
nt
Step Key
Increme
nt
EVM vs.
Symbol
0 21847 Symb 0 1 10
Spectral
Flatness
-2048 2048 Carr -28 1 10
Unused
Tone
Error
-2048 2048 Carr -28 1 10
Respons
e
Frequenc
y
Respons
e
-2048 2048 Carr -28 1 10
Equalizer
Impulse
Respons
e
-1s 1s ks /s / ms
/ us / ns
-1.6us 0.01us 0.1us
Pre
Demod
SEM
Summary
-
1000G
1000G Hz / kHz /
MHz /
GHz
2.412GH
z
0.1MHz 1MHz
Scale/Div
Sets the horizontal scale.
Remote
Command
:DISPlay:EVMMimo:WINDow[1]|2|…|9:TRACe:X[:SCALe]:PDIVision <real>
:DISPlay:EVMMimo:WINDow[1]|2|…|9:TRACe:X[:SCALe]:PDIVision?
Example
:DISP:EVMM:WIND2:TRAC:X:PDIV 500
:DISP:EVMM:WIND2:TRAC:X:PDIV?
Couplings If Auto Scaling is set to On, this value is automatically determined by the measurement result. When you
set this value manually, Auto Scaling automatically changes to Off
Preset Auto
State Saved Yes Saved in instrument state
Min/Max See table below
1301 WLAN Mode User's &Programmer's Reference
