3 WLAN Mode
3.6 Modulation Analysis Measurement
RU/MRU RU Size
996+996+484+[gap-484]+996 3477
996+996+996+[gap-484]+484 3478
996+996+996+484+[gap-484] 3479
4x996 3984
‘+’ indicate this is an MRU. An MRU consists of selected combinations of multiple RUs of 26-tone RU,
52-tone RU, 106-tone RU, 242-tone RU, 484-tone RU, 996-tone RU, and 2.996-tone RU. [gap-xxx]
represents a null allocation with size xxx.
RU State
Determines the state of each RU.
This is a list of parameters, and the length of the list is the number of RUs.
Remote Command
[:SENSe]:DEMod[:WLAN]:RU:LIST:STATe OFF | ON | 0 | 1,…
[:SENSe]:DEMod[:WLAN]:RU:LIST:STATe?
Example
:DEM:RU:LIST:STAT 1,1,0,0,0,0,0,0,0
:DEM:RU:LIST:STAT?
Notes The length of the list is variable and determined by the number of RUs
Dependencies Only available for 802.11ax/ 802.11be
Preset
ON
State Saved Saved in instrument state
Tx Chain Number of Each RU
This parameter determines TX chain number of each RU.
This is a list of parameters, and the length of the list is the number of RUs.
Remote Command
[:SENSe]:DEMod[:WLAN]:RU:LIST:TXCHain <integer>,<integer>,<integer>,…
[:SENSe]:DEMod[:WLAN]:RU:LIST:TXCHain?
Example
:DEM:RU:LIST:TXCH 1,1
:DEM:RU:LIST:TXCH?
Notes The length of the list is variable and determined by the number of RUs
Dependencies Only available for 802.11ax/ 802.11be
Preset
1
State Saved Saved in instrument state
