3 WLAN Mode
3.8 Power vs Time Measurement
State Saved Saved in instrument state. Not affected by Marker Off and hence not affected by Preset or power cycle.
Min 1
Max 12
Annunciation Appears in the marker label of a Delta marker.
Marker Trace
Assigns the specified marker to the designated trace.
Remote
Command
:CALCulate:PVTime:MARKer[1]|2|...|12:TRACe POLar | EVM | MERRor | PERRor |
EVMS | EVMC | PFERror | IQGain | IQQuad | IQTime | UTERror
:CALCulate:PVTime:MARKer[1]|2|...|12:TRACe?
Example
:CALC:PVTime:MARK:TRAC EVM
:CALC:PVTime:MARK:TRAC?
Notes EVM, MERRor, PERRor, PFERrorwill be avaiable if the Raido Std is 802.11b/g (DSSS/CCK/PBCC),
otherwise they are grayed out
EVMS and EVMC will be availble if the Radio Std is 802.11a/g/j/p (OFDM), 801.11g (DSSS-OFDM),
802.11n, 802.11ac or 802.11ah otherwise they are grayed out
IQGain, IQQuad, and IQTime will be available if the Raido Std is 802.11n , 802.11ac or 802.11ah,
otherwise they are grayed out.
Preset POLar
State Saved Yes
Range IQ Measured Polar ContIn | EVM vs. Symbol | EVM vs. Carrier | Mag Error | Phase Error I EVM | Preamble
Freq Error | IQ Gain vs. Carrier | IQ Quad Skew vs. Carrier | Unused Tone Error
Marker Settings Diagram
The Marker Settings Diagram lets you configure the Marker system using a visual
utility.
