3 WLAN Mode
3.12 IQ Waveform Measurement
3.12.7 Marker
Displays a menu that enables you to select, set up and control the markers for the
current measurement.
If there are no active markers, Marker selects Marker 1, sets it to POSition
(Normal) mode, and places it at the center of the display. If the selected marker is
OFF, it is set to POSition mode and placed at the center of the screen, on the trace
determined by the Marker Trace rules.
For details of the POSition, DELTa, and OFF mode options, see "Marker Mode" on
page 1816.
3.12.7.1 Select Marker
Sets the selected marker. The term “selected marker” is used throughout this
document to specify which marker will be affected when you change marker
settings, perform a Peak Search, etc.
The Select Marker control appears above the menu panel, indicating that it applies
to all controls in the Marker menu panels. Select Marker is blanked if you select a
tab whose controls do not depend on the selected marker (for example, Counter).
For any menu that includes Select Marker, the first control is always "Marker Time"
on page 1813.
Notes The selected marker is remembered even when not in the Marker menu and is used if a Search is done
or a Band Function is turned on or for Signal Track or Continuous Peak
Preset Marker 1
State Saved The number of the selected marker is saved in instrument state
Annunciation Appears in the marker results block label for POSition and Delta markers
3.12.7.2 Settings
The controls on this tab include the Marker active function and a radio button
selection for "Marker Mode" on page 1816 (POSition, DELTa, or OFF) for the
selected marker, as well as additional functions that help you use markers.
Marker Time
This is the fundamental control that you use to move a marker around on the trace.
Because it is the default active function in the Marker menu, all you need to do is
press Marker and turn the knob to move the marker left and right on the display.
1813 WLAN Mode User's &Programmer's Reference
