3 WLAN Mode
3.9 Spectral Flatness Measurement
If Radio Std is 802.11ax 40MHz: -244 Carr
If Radio Std is 802.11ax 80MHz: -500 Carr
If Radio Std is 802.11ax 160MHz: -1012 Carr
If Radio Std is 802.11be 20MHz: -122 Carr
If Radio Std is 802.11be 40MHz: -244 Carr
If Radio Std is 802.11be 80MHz: -500 Carr
If Radio Std is 802.11be 160MHz: -1012 Carr
If Radio Std is 802.11be 320MHz: -2036 Carr
State Saved Yes
Min/Max -2048.0 Carriers / 2048.0 Carriers
Scale/Div
Enables you to set the display X scale/division value.
Remote
Command
:DISPlay:FLATness:WINDow[1]:TRACe:X[:SCALe]:PDIVision <time>
:DISPlay:FLATness:WINDow[1]:TRACe:X[:SCALe]:PDIVision?
Example
:DISP:FLAT:WIND:TRAC:X:PDIV 1
:DISP:FLAT:WIND:TRAC:X:PDIV?
Couplings If X Auto Scaling is On, this value is automatically determined by the measurement result. When you set
a value manually, X Auto Scaling automatically changes to Off.
Preset If Radio Std is 802.11a/g-ERP-OFDM/g-DSSS-OFDM: 5.2 Carr
If Radio Std is 802.11n/ac 20MHz or 802.11ah 2MHz: 5.6 Carr
If Radio Std is 802.11n/ac 40MHz, 802.11ah 4MHz or 802.11af 6/7/8MHz: 11.6 Carr
If Radio Std is 802.11ac 80MHz or 802.11ah 8MHz: 24.4 Carr
If Radio Std is 802.11ac 160MHz or 802.11ah 16MHz: 50.0 Carr
If Radio Std is 802.11ah 1MHz: 2.6 Carr
If Radio Std is 802.11ax 20MHz: 24.4 Carr
If Radio Std is 802.11ax 40MHz: 48.8 Carr
If Radio Std is 802.11ax 80MHz: 100 Carr
If Radio Std is 802.11ax 160MHz: 202.4 Carr
If Radio Std is 802.11be 20MHz: 24.4 Carr
If Radio Std is 802.11be 40MHz: 48.8 Carr
If Radio Std is 802.11be 80MHz: 100 Carr
If Radio Std is 802.11be 160MHz: 202.4 Carr
If Radio Std is 802.11be 320MHz: 407.2 Carr
State Saved Yes Saved in instrument state.
Min/Max 0.1 carriers /409.6 carriers
WLAN Mode User's &Programmer's Reference 1534
