3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Couplings Default Value is coupled with Radio Std
Preset CONS
State Saved Saved in instrument state
I/Q Points
Specifies the number of I/Q Points displayed for the I/Q measured polar graph.
Remote
Command
:DISPlay:EVMMimo:VIEW[1]:WINDow[1]:TRACe:IQPoints <integer>
:DISPlay:EVMMimo:VIEW[1]:WINDow[1]:TRACe:IQPoints?
Example
:DISP:EVMM:VIEW:WIND:TRAC:IQP 10
:DISP:EVMM:VIEW:WIND:TRAC:IQP?
Notes Default, Max values are coupled with Radio Std and Meas Interval
Couplings Change the Meas Interval will set the I/Q Points as the same number as Meas Interval when Meas
Interval is no bigger than 24564, otherwise, it will be clipped to 24564
Preset 60 symbols
State Saved Saved in instrument state
Min 1
Max Meas Interval, when Meas Interval <= 24564
24564, when Meas Interval> 24564
I/Q Points Offset
Specifies the number of points offset from the first one in the Meas Interval.
Remote
Command
:DISPlay:EVMMimo:VIEW[1]:WINDow[1]:TRACe:IQOFfset <integer>
:DISPlay:EVMMimo:VIEW[1]:WINDow[1]:TRACe:IQOFfset?
Example
:DISP:EVMM:VIEW:WIND:TRAC:IQOF 10
:DISP:EVMM:VIEW:WIND:TRAC:IQOF?
Notes Max Value is coupled with Meas Interval and I/Q Points
Couplings Change of Meas Interval will set the I/Q Points Offset to be 0
Preset 0
State Saved Saved in instrument state
Min 0
Max Meas Interval – I/Q Points
