Keysight M9421A - HE Guard Interval Selection (Radio Std 802.11 ax)

3 WLAN Mode
3.6 Modulation Analysis Measurement
:DEM:AX80:HESC:SPAC 78.125 kHz
:DEM:AX80:HESC:SPAC?
Radio Std = 802.11ax 80+80 MHz
:DEM:AXT80:HESC:SPAC 78.125 kHz
:DEM:AXT80:HESC:SPAC?
Radio Std = 802.11ax 160 MHz
:DEM:AX160:HESC:SPAC 78.125 kHz
:DEM:AX160:HESC:SPAC?
Preset 78.125kHz
State Saved Saved in instrument state
Min/Max 1 Hz / 1.25 MHz
HE Guard Interval Selection (Radio Std 802.11ax)
Specifies the guard interval (also called cyclic extension) length for each symbol
time, as a fraction of the FFT length. The value must match the guard interval length
actually used in the input signal in order for demodulation to work properly. The
value should be between zero and one, and values outside that range are clipped to
be within the range. The value is rounded to the nearest 1/128th. The 802.11ax HE
Guard Interval is for HE part of signal, the Guard Interval of Non-HE part is fixed to
¼. The Auto selection allows to detect 11ax HE Guard Interval automatically.
Remote
Command
Radio Std = 802.11ax 20 MHz
[:SENSe]:DEMod[:WLAN]:AX20:GINTerval AUTO | R1B4 | R1B8 | R1B16 | SIG | OTHer
[:SENSe]:DEMod[:WLAN]:AX20:GINTerval?
Radio Std = 802.11ax 40 MHz
[:SENSe]:DEMod[:WLAN]:AX40:GINTerval AUTO | R1B4 | R1B8 | R1B16 | SIG | OTHer
[:SENSe]:DEMod[:WLAN]:AX40:GINTerval?
Radio Std = 802.11ax 80 MHz
[:SENSe]:DEMod[:WLAN]:AX80:GINTerval AUTO | R1B4 | R1B8 | R1B16 | SIG | OTHer
[:SENSe]:DEMod[:WLAN]:AX80:GINTerval?
Radio Std = 802.11ax 80+80 MHz
[:SENSe]:DEMod[:WLAN]:AXT80:GINTerval AUTO | R1B4 | R1B8 | R1B16 | SIG |
OTHer
[:SENSe]:DEMod[:WLAN]:AXT80:GINTerval?
Radio Std = 802.11ax 160 MHz
[:SENSe]:DEMod[:WLAN]:AX160:GINTerval AUTO | R1B4 | R1B8 | R1B16 | SIG |
OTHer
[:SENSe]:DEMod[:WLAN]:AX160:GINTerval?
