3 WLAN Mode
3.6 Modulation Analysis Measurement
Radio Std <radio_
std>
<options>
802.11ah 1 MHz
AH1 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|SIG
802.11ah 2 MHz
AH2 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|SIG
802.11ah 4 MHz
AH4 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|SIG
802.11ah 8 MHz
AH8 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|SIG
802.11ah 16 MHz
AH16 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|SIG
802.11af 6 MHz
AF6 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|SIG
802.11af 7 MHz
AF7 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|SIG
802.11af 8 MHz
AF8 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|SIG
802.11ax 20 MHz
AX20 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11ax 40 MHz
AX40 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11ax 80 MHz
AX80 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11ax 80+80
MHz
AXT80 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11ax 160 MHz
AX160 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11be 20 MHz
BE20 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11be 40 MHz
BE40 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11be 80 MHz
BE80 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11be 160
MHz
BE160 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11be 320
MHz
BE320 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
Subcarrier Spacing (Radio Std NOT 802.11b/g(DSSS/CCK/PBCC) or 802.11ax, 802.11be)
Specifies the subcarrier frequency spacing of the input signal. This parameter must
match the actual subcarrier frequency spacing of the input signal, otherwise
demodulation will fail. The default 312.5 kHz matches the 802.11a/g/n/ac
standards.
Remote
Command
Radio Std = 802.11a/g/j/p(OFDM 20 MHz)
[:SENSe]:DEMod[:WLAN]:AG:SUBCarrier:SPACing <freq>
[:SENSe]:DEMod[:WLAN]:AG:SUBCarrier:SPACing?
Radio Std = 802.11g(DSSS-OFDM)
983 WLAN Mode User's &Programmer's Reference
