3 WLAN Mode
3.6 Modulation Analysis Measurement
AUTO | BPSK | QPSK | 16QAM | 64QAM | SIG
Radio Std = 802.11ac 20 MHz, 40 MHz, 80 MHz, 80+80 MHz, 160 MHz
AUTO | BPSK | QPSK | 16QAM | 64QAM | 256QAM | 1024QAM | 4096QAM | SIG
Radio Std = 802.11ah 1 MHz, 2 MHz, 4 MHz
AUTO | BPSK | QPSK | 16QAM | 64QAM | 256QAM | SIG
Radio Std = 802.11ah 8 MHz, 16 MHz
AUTO | BPSK | QPSK | 16QAM | 64QAM | 256QAM | SIG
Radio Std = 802.11af 6 MHz, 7 MHz, 8 MH
AUTO | BPSK | QPSK | 16QAM | 64QAM | 256QAM | SIG
Radio Std = 802.11ax 20 MHz, 40 MHz, 80 MHz, 80+80 MHz, 160 MHz
AUTO | BPSK | QPSK | 16QAM | 64QAM | 256QAM | 1024QAM | 4096QAM | SIG
Radio Std = 802.11be 20 MHz, 40 MHz, 80 MHz, 160 MHz, 320MHz
AUTO | BPSK | QPSK | 16QAM | 64QAM | 256QAM | 1024QAM | 4096QAM | SIG
Radio Standard Keywords & Options
Radio Std <radio_
std>
<options>
802.11a/g/j/p
(OFDM 20 MHz)
AG AUTO|BPSK|QPSK|QAM16|QAM64
802.11b/g
(DSSS/CCK/PBC
C)
BG AUTO|DSSS1|DSSS2|CCK55|CCK11|PBCC55|PBCC11|PBCC2
2|PBCC33
802.11g (DSSS-
OFDM)
GDO AUTO|BPSK|QPSK|QAM16|QAM64
802.11j/p (OFDM
10 MHz)
JP10 AUTO|BPSK|QPSK|QAM16|QAM64
802.11j/p (OFDM
5 MHz)
P5 AUTO|BPSK|QPSK|QAM16|QAM64
802.11n 20 MHz
N20 AUTO|BPSK|QPSK|QAM16|QAM64|SIG
802.11n 40 MHz
N40 AUTO|BPSK|QPSK|QAM16|QAM64|SIG
802.11ac 20 MHz
AC20 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11ac 40 MHz
AC40 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11ac 80 MHz
AC80 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11ac 80+80
MHz
ACT80 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
802.11ac 160
MHz
AC160 AUTO|BPSK|QPSK|QAM16|QAM64|QAM256|QAM1024|QAM409
6|SIG
