3 WLAN Mode
3.9 Spectral Flatness Measurement
NOTE
Pressing the Peak Search hardkey automatically moves you to the Peak Search
page of the Marker menu AND performs a Peak Search.
NOTE
Pressing the Peak Search tab once you are already IN the Marker menu does
NOT perform a Peak Search.
Marker X Value
The Marker Frequency control is the fundamental control that you use to move a
marker around on the trace. This is the same as the "Marker X Value" on page 1478
on the Settings tab.
Peak Search
Pressing the Peak Search control moves the selected marker to the trace point
which has the maximum y-axis value for that marker’s trace.
NOTE
Pressing the Peak Search hardkey automatically moves you to the Peak Search
page of the Marker menu AND performs a Peak Search.
Remote
Command
:CALCulate:FLATness:MARKer[1]|2|...|12:MAXimum
Example
:CALC:FLATness:MARK2:MAX
The command SYST:ERR? can be used to query the errors to determine if a peak is found. The message
“No peak found” will be returned after an unsuccessful search.
Next Peak
Pressing Next Peak moves the selected marker to the peak that is next lower in
amplitude than the current marker value. If there is no valid peak lower than the
current marker position, a “No peak found” message is generated and the marker is
not moved.
If the selected marker was off, it is turned on as a normal marker and a peak search
is performed.
Remote Command
:CALCulate:FLATness:MARKer[1]|2|...|12:MAXimum:NEXT
Example
:CALC:FLATness:MARK2:MAX:NEXT
State Saved Not Saved in instrument state
WLAN Mode User's &Programmer's Reference 1484
