3 WLAN Mode
3.3 Occupied BW Measurement
3.3.1.2 OBW Boundaries
Windows: "Graph" on page 332, "Metrics - OBW Boundaries" on page 335
The spectrum trace is displayed in the upper window. The lower window of OBW
Results view is replaced by the OBW boundaries table in this view. Occupied
bandwidth and X dB bandwidth for both lower and upper boundaries are displayed.
Example
:DISP:OBW:VIEW BOUN
3.3.1.3 Gate
See "Gate View On/Off" on page 2494
3.3.2 Windows
There are four available window types. The Gate window is available only when
"Gate View On/Off" on page 2494 is ON in the Gate Settings menu under Trigger.
View #
"Graph" on page 332 1
"OBW Results" on page 331 2
"OBW Boundaries" on page 332 3
"Gate" on page 336 4
3.3.2.1 Graph
Window #1
Appears in two Views, as follows:
View Size Position
"OBW Results" on page 331 Three fifth, full width Top
"OBW Boundaries" on page 332 Half, full width Top
Spectrum View
For SA, WCDMA, WLAN mode:
WLAN Mode User's &Programmer's Reference 332
