3 WLAN Mode
3.6 Modulation Analysis Measurement
Sets 6 Mbits/s RMS EVM limit to warn you if the measured average RMS EVM value
exceeds a limit.
Remote Command
:CALCulate:EVM:LIMit:RMS:M6 <rel_ampl>
:CALCulate:EVM:LIMit:RMS:M6?
Example
:CALC:EVM:LIM:RMS:M6 -20
:CALC:EVM:LIM:RMS:M6?
Notes This limit value is used in 802.11a/g/j/p (OFDM 20M), 801.11g (DSSS-OFDM)
Preset -5.00 dB
State Saved Saved in instrument state
Min -1000.00
Max 0.00
9 Mbits/s RMS EVM
This parameter is available when Radio Std is 802.11a/b/g/j/p OFDM 20 MHz or
802.11g DSSS-OFDM.
Sets 9 Mbits/s RMS EVM limit to warn you if the measured average RMS EVM value
exceeds a limit.
Remote Command
:CALCulate:EVM:LIMit:RMS:M9 <rel_ampl>
:CALCulate:EVM:LIMit:RMS:M9?
Example
:CALC:EVM:LIM:RMS:M9 -20
:CALC:EVM:LIM:RMS:M9?
Notes This limit value is used in 802.11a/g/j/p (OFDM 20M), 801.11g (DSSS-OFDM)
Preset -8.00 dB
State Saved Saved in instrument state
Min -1000.00
Max 0.00
12 Mbits/s RMS EVM
This parameter is available when Radio Std is 802.11a/b/g/j/p OFDM 20 MHz or
802.11g DSSS-OFDM.
Sets 12 Mbits/s RMS EVM limit to warn you if the measured average RMS EVM value
exceeds a limit.
Remote Command
:CALCulate:EVM:LIMit:RMS:M12 <rel_ampl>
:CALCulate:EVM:LIMit:RMS:M12?
Example
:CALC:EVM:LIM:RMS:M12 -20
1045 WLAN Mode User's &Programmer's Reference
