7 Save/Recall/Print
7.2 Recall
Example
:MMEM:LOAD:EVM:REC:RES
7.2.41 Recalled data channel table (Display only)
Displays recalled IQ data file for each channel in a table.
7.2.42 CC Setup
You can recall a Component Carrier Setup file, which sets up the 5G NR Modulation
Analysis measurement with the settings in the file.
Using the Component Carrier dropdown, you can specify which component carrier
you wish to apply this setup to, or ALL.
The following file formats are supported:
Format Extension
Signal Studio N7631C Setup
.scp
M9384B VXG 5GNR Setup
.sgen
PWSG Desktop Setup
.pwsg
89600 VSA 5GNR Setup
.setx
X-Series Measurement Application 5GNR Component Carrier Setup
.nrcc
Remote
Command
:MMEMory:LOAD:EVM:SETup ALL | CC0 | CC1 | CC2 | CC3 | CC4 | CC5 | CC6 | CC7
| CC8 | CC9 | CC10 | CC11 | CC12 | CC13 | CC14 | CC15,<string>
Example
:MMEM:LOAD:EVM:SET CC0,"mySetup.scp"
Status Bits/OPC
dependencies
Sequential - aborts the current measurement
7.2.43 Frame Index (.scp and .pwsg only)
Signal Studio (N7631C) and PWSG desktop may have configuration for multiple
frames. This parameter specifies which frame’s configuration will be recalled in
5GNR Modulation Analysis measurement from a .scp or .pwsg file.
Remote Command
:MMEMory:LOAD:EVM:FRAMe <int>
:MMEMory:LOAD:EVM:FRAMe?
Example
:MMEM:LOAD:EVM:FRAM 1
:MMEM:LOAD:EVM:FRAM?
Preset 0
WLAN Mode User's &Programmer's Reference 2373
