Keysight M9421A - RU Allocation Index; RU Size

3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Example
:DEM:RU:LIST:MCS 0,11,0,11,0,11,0,11,0
:DEM:RU:LIST:MCS?
Notes The length of the list is variable and determined by the number of RUs
Dependencies Only available for 802.11ax/ 802.11be
Preset 0
State Saved Saved in instrument state
Min 0
Max 11
RU Allocation Index
This parameter determines the RU allocation index for each 20MHz sub band. It may
contain multiple small-size RUs/MRUs or a large-size RU/MRU that may span
multiple 20MHz sub bands including the current sub band.
Remote Command
[:SENSe]:DEMod[:WLAN]:RU:ALLocation[01]|2|…|16 <string>
[:SENSe]:DEMod[:WLAN]:RU:ALLocation[01]|2|…|16?
Example
:DEM:RU:ALL ‘00000000’
:DEM:RU:ALL?
Notes
String lengh is 8 for 11ax and 9 for 11be.
Valid character is only 0 and 1.
Dependencies Only available for 11ax/be.
Preset
11ax 11000000
11be 001000000
State Saved Saved in instrument state
RU Size
This parameter determines the size of each RU.
This is a list of parameters, and the length of the list is the number of RUs.
Remote Command
[:SENSe]:DEMod[:WLAN]:RU:LIST:SIZE <integer>,<integer>,<integer>,…
[:SENSe]:DEMod[:WLAN]:RU:LIST:SIZE?
Example
:DEM:RU:LIST:SIZE 26,26,26,26,26,26,26,26,26
:DEM:RU:LIST:SIZE?
Notes The length of the list is variable and determined by the number of RUs
Dependencies Only available for 802.11ax/ 802.11be
Preset 242
WLAN Mode User's &Programmer's Reference 1256
