3 WLAN Mode
3.12 IQ Waveform Measurement
View 2 is the I/Q Waveform View
Couplings If X "Auto Scaling" on page 1860 is ON, this value is automatically determined by the measurement
result. When you set a value manually, X Auto Scaling automatically changes to OFF
Preset 0.000 s
State Saved Saved in instrument state
Min/Max -1 s /10.0 s
Annotation <value> s bottom left of graph
Scale/Div
Sets the display X scale/division value.
Remote
Command
:DISPlay:WAVeform:VIEW[1]|2:WINDow[1]:TRACe:X[:SCALe]:PDIVision <time>
:DISPlay:WAVeform:VIEW[1]|2:WINDow[1]:TRACe:X[:SCALe]:PDIVision?
Example
:DISP:WAV:VIEW:WIND:TRAC:X:PDIV 500 us
:DISP:WAV:VIEW:WIND:TRAC:X:PDIV?
Notes View 1 is the RF Envelope View
View 2 is the I/Q Waveform View
Couplings If X "Auto Scaling" on page 1860 is ON, this value is automatically determined by the measurement
result. When you set a value manually, X Auto Scaling automatically changes to OFF
Preset 200.0 us
State Saved Saved in instrument state
Min 1.00 ns
Max 320 s
Ref Position
Sets the reference position for the X axis to LEFT, CENTer or RIGHt.
Remote
Command
:DISPlay:WAVeform:VIEW[1]|2:WINDow[1]:TRACe:X[:SCALe]:RPOSition LEFT | CENTer
| RIGHt
:DISPlay:WAVeform:VIEW[1]|2:WINDow[1]:TRACe:X[:SCALe]:RPOSition?
Example
:DISP:WAV:VIEW:WIND:TRAC:X:RPOS LEFT
:DISP:WAV:VIEW:WIND:TRAC:X:RPOS?
Preset
LEFT
State Saved Saved in instrument state
Range
LEFT|CENTer|RIGHt
1859 WLAN Mode User's &Programmer's Reference
