3 WLAN Mode
3.10 Power Stat CCDF Measurement
Enum value AXT80 means “AX Two 80MHz” (802.11ax 80+80 MHz)
Preset
AG
State Saved Saved in instrument state
Range 802.11a/g/j/p (OFDM 20M) | 802.11b/g (DSSS/CCK/PBCC) | 802.11g (DSSS-OFDM) | 802.11n (20
MHz) | 802.11n (40 MHz) | 802.11ac (20 MHz) | 802.11ac (40 MHz) | 802.11ac (80 MHz) | 802.11ac (80
+ 80MHz)| 802.11ac (160MHz) | 802.11ah(1MHz) | 802.11ah(2MHz) | 802.11ah(4MHz) | 802.11ah
(8MHz) | 802.11ah(16MHz) | 802.11j/p (OFDM 10M) | 802.11p (OFDM 5M) | 802.11af (6MHz)|802.11af
(7Mhz) | 802.11af (8MHz) | 802.11ax (20 MHz) | 802.11ax (40 MHz) | 802.11ax (80 MHz) | 802.11ax (80 +
80MHz)| 802.11ax (160MHz) | 802.11be (20 MHz) | 802.11be (40 MHz) | 802.11be (80 MHz) | 802.11be
(160MHz)| 802.11be (320MHz)
3.10.8.3 Advanced
Contains controls for setting advanced functions of the instrument.
IF Gain
Used to set the IF Gain function to: Auto, Low Gain or High Gain. These settings
affect sensitivity and IF overloads.
Only applies to the RF input. Does not apply to baseband I/Q input.
Remote Command
[:SENSe]:PSTatistic:IF:GAIN[:STATe] ON | OFF | 1 | 0
[:SENSe]:PSTatistic:IF:GAIN[:STATe]?
Example
:PST:IF:GAIN ON
:PST:IF:GAIN?
Notes ON = high gain
OFF = low gain
Dependencies Not available when IQ Input is selected
Has no effect when the U7227A USB Preamplifier is connected. This is not annotated or reflected on
any control; there are no controls grayed out nor any SCPI locked out. The instrument simply behaves
as though both IF Gain is set to Low regardless of the setting on the control
Not available in VXT, EXM, or UXM
Couplings Sending this command forces IF Gain Auto to OFF (Man)
Preset
OFF
State Saved Saved in instrument state
Range Low Gain | High Gain
Auto Function
Remote
Command
[:SENSe]:PSTatistic:IF:GAIN:AUTO[:STATe] ON | OFF | 1 | 0
[:SENSe]:PSTatistic:IF:GAIN:AUTO[:STATe]?
1617 WLAN Mode User's &Programmer's Reference
