Keysight M9421A - U-Sig No; EHT SIG No

3 WLAN Mode
3.6 Modulation Analysis Measurement
U-Sig No
The U-SIG content shall be identical in each non-punctured 20 MHz subchannels
within each 80 MHz subblock, while it can be different in each 80 MHz subblocks
when BW is greater than 80MHz.
You can choose ‘U-SIG No’ to see decoded information for each 80 MHz subblock.
Remote Command
:DISPlay:EVM:USIG[:NUMBer] <integer>
:DISPlay:EVM:USIG[:NUMBer]?
Example
:DISP:EVM:USIG 1
:DISP:EVM:USIG?
Preset 1
State Saved Saved in instrument state
Min 1
Max 1 for 11be 20M/40M/80M
2 for 11be 160M
4 for 11be 320M
EHT SIG No
For OFDMA transmission or non-OFDMA transmission to multiple users, EHT-SIG
field when BW is greater than 80 MHz contains two EHT-SIG content channels per
80 MHz and the EHT-SIG content channels per 80 MHz are allowed to carry
different information.
You can choose EHT-SIG No to see EHT-SIG filed decoded information for each 80
MHz subblock.
Remote Command
:DISPlay:EVM:EHTSig[:NUMBer] <integer>
:DISPlay:EVM:EHTSig[:NUMBer]?
Example
:DISP:EVM:EHTS 1
:DISP:EVM:EHTS?
Preset 1
State Saved Saved in instrument state
Min 1
Max 1 for 11be 20M/40M/80M
2 for 11be 160M
4 for 11be 320M
941 WLAN Mode User's &Programmer's Reference
