Keysight M9421A - Power Reference Plane

3 WLAN Mode
3.6 Modulation Analysis Measurement
Remote Command
[:SENSe]:EVM:CCEVm[:ENABle] OFF | ON | 0 | 1
[:SENSe]:EVM:CCEVm[:ENABle]?
Example
:EVM:CCEV 1
:EVM:CCEV?
Notes Before ccEVM, Remote Analyzer should be configured in Meas Setup\Global\Remote Analyzer Config.
See "Remote Analyzer Config" on page 1077.
Dependencies Grayed out for 802.11ajgp/11b/11ah/11af, 802.11ac/ax 80 MHz + 80 MHz and Radio Std Detection is
On
Preset
OFF
State Saved Saved in instrument state
Range On | Off
Power Reference Plane
Allows you to increase the power by 3dB for Baseband I+jQ measurements. Options
are:
Menu SCPI
Baseband
BASeband
RF
RF
Remote Command For valid <meas> values, see "Valid Measurement Keywords" on page 1074
[:SENSe]:<meas>:POWer:IQ:REFerence:PLANe RF | BASeband
[:SENSe]:<meas>:POWer:IQ:REFerence:PLANe?
Example (Complex Spectrum measurement)
SPEC:POW:IQ:REF:PLAN BAS
SPEC:POW:IQ:REF:PLAN?
Dependencies Only available if the I/Q input exists
Enabled only when the input is I/Q and I/Q Path is I+jQ
Disabled for all other conditions
Preset
RF
State Saved Saved in instrument state
Valid Measurement Keywords
This function is available only in certain Modes and measurements. Only the
following listed values of <meas> are valid.
WLAN Mode User's &Programmer's Reference 1074
