3 WLAN Mode
3.6 Modulation Analysis Measurement
Auto Scaling
Toggles the scale coupling function between On and Off.
Remote
Command
:DISPlay:EVM:WINDow3|4|5|7|8|14|15|16|20:TRACe:X[:SCALe]:COUPle 0 | 1 | OFF
| ON
:DISPlay:EVM:WINDow3|4|5|7|8|14|15|16|20:TRACe:X[:SCALe]:COUPle?
The applicable windows are numbered as follows:
:Window :Number
:Magnitude Error :3
:Phase Error :4
:EVM vs. Chips :5
:EVM vs. Symbol :7
:EVM vs. Carrier :8
:Preamble Freq Error :14
:I/Q Gain Imbalance :15
:I/Q Quadrature Skew :16
:Unused Tone Error :20
:Power vs. Symbol :22
Example
:DISP:EVM:WIND7:TRAC:X:COUP ON
:DISP:EVM:WIND7:TRAC:X:COUP?
Couplings When this parameter is set to On, pressing the front-panel Restart key activates the scale coupling
function, that automatically determines scale per division and reference values based on the
measurement results. When you set a value to either Scale/Div or Ref Value manually, Auto Scaling is
automatically set to Off
Preset
ON
State Saved Saved in instrument state
Range On|Off
Backwards
Compatibility
SCPI
:DISPlay:EVM:VIEW10:WINDow1:TRACe:X[:SCALe]:COUPle 0 | 1 | OFF | ON
:DISPlay:EVM:VIEW10:WINDow1:TRACe:X[:SCALe]:COUPle?
3.6.9.3 Recording
Displays the Sample Rate, Sample Points and Sample Time of the saved IQ data file.
Recording and playback of signal data files is a multi-step process that involves
controls in several menus:
1095 WLAN Mode User's &Programmer's Reference
