3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
3.7.9.10 Global
Remote Analyzer Config
The X-Series Signal Analyzers have a single RF channel. For the multi-channel
measurement scenarios, such as MIMO, multiple X-Series Signal Analyzers can be
configured to create a multi-analyzer system. The following setup establishes the
LAN communication for the multi-analyzer system.
IP Address
Lets you enter a new IP address of the remote analyzer. After you enter the address
you should press “Add” to add the analyzer at that address to the Available Analyzer
List.
Preset 0.0.0.0
State Saved No
SCPI Socket Port
Let you enter a new SCPI socket port number of the remote analyzer. After you
enter the number you should press “Add” to add the analyzer at that address to the
Available Analyzer List.
Preset 5025
State Saved No
Add Analyzer
Adds the new analyzer to the remote analyzer list. When pressing this softkey, the
following items will be checked:
1.
Whether it is a new one to the remote analyzer list.
2.
Whether the IP address is valid.
3.
Whether the SCPI socket port number is valid.
4.
Whether the IP address is the local IP address or not.
5.
Whether the IP address has been added or not.
6.
Whether the IP address can be visited by TCPIP.
