Keysight M9421A - Max Result Length; From SIG Symbols

3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
:EVMM:TIME:RES:LENG:AUTO?
Preset 802.11a/g/j/p (OFDM), 801.11g (DSSS-OFDM), 802.11n/ac/ah/af/ax/be: 16 symbols
802.11b/g (DSSS/CCK/PBCC): 2816 chips s
ON
State Saved Saved in instrument state
Saved in instrument state
Range Auto|Man
Min 2 symbols
Max 21848 symbols
Max Result Length
Max Result Length specifies a maximum result length.
If the auto-detected length is greater than the specified maximum result length, the
maximum result length is used instead.
The actual results returned will be for a subset of this maximum, as specified by the
Meas Interval and Meas Offset, and will be further limited to the auto-detected
result length if that is shorter than the maximum result length.
Remote
Command
[:SENSe]:EVMMimo:TIME:RESult:LENGth:MAX <integer>
[:SENSe]:EVMMimo:TIME:RESult:LENGth:MAX?
Example
:EVMM:TIME:RES:LENG:MAX 45
:EVMM:TIME:RES:LENG:MAX?
Preset 802.11a/g/j/p (OFDM), 801.11g (DSSS-OFDM802.11n/ac/ah/af/ax/be: 16 symbols
802.11b/g (DSSS/CCK/PBCC): 2816 chips
State Saved Saved in instrument state
Min 2 symbols
Max 21848 symbols
From SIG Symbols
–
If From SIG Syms is On:
The Result Length is detected from the High Throughput Signal Field. It compares
the decoded length information to the Max Result Length parameter and uses the
smaller value as the measurement result length.
WLAN Mode User's &Programmer's Reference 1236
