Keysight M9421A - Marker Mode; Delta Marker (Reset Delta)

3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Marker Mode
Sets the marker control mode to Normal, Delta, or Off.
All interactions and dependencies detailed under the control description are
enforced when the remote command is sent. If the selected marker is Off, pressing
Marker sets it to Normal and places it at the center of the screen on the trace
determined by the Marker Trace rules.
The default active function is the active function for the currently selected marker
control mode. If the current control mode is Off, there is no active function, and the
active function is turned off.
Remote
Command
:CALCulate:EVMMimo:MARKer[1]|2|…|12:MODE POSition | DELTa | OFF
:CALCulate:EVMMimo:MARKer[1]|2|…|12:MODE?
Example
:CALC:EVMM:MARK3:MODE POS
:CALC:EVMM:MARK3:MODE?
Preset OFF
State Saved Saved in instrument state
Range Normal | DELTa (D) | Off
Backwards Compatibility SCPI Commands
Sets or queries the state of a marker. Setting a marker which is OFF to state ON or 1
puts it in Normal mode and places it at the center of the screen.
Example
:CALC:EVMMimo:MARK3:STAT ON
:CALC:EVMMimo:MARK3:STAT?
Preset OFF
State Saved Saved in instrument state
Range On|Off
Backwards
Compatibility
SCPI
:CALCulate:EVMMimo:MARKer[1]|2|…|12:STATe OFF | ON | 0 | 1
:CALCulate:EVMMimo:MARKer[1]|2|…|12:STATe?
Delta Marker (Reset Delta)
Pressing this button is exactly the same as pressing the “Delta” selection on the
Marker Mode radio button. The selected marker becomes a Delta Marker. If the
selected marker is already a Delta marker, the reference marker is moved to the
current position of the selected marker, thus resetting the Delta to zero.
1189 WLAN Mode User's &Programmer's Reference
