Keysight M9421A - Auto Scaling

3 WLAN Mode
3.8 Power vs Time Measurement
:DISP:PVT:WIND3:TRAC:X:RPOS RIGHt
3-Fall for Transmit On/Off Power
Preset CENTer
State Saved Yes Saved in instrument state.
Range Left|Ctr|Right
Backwards Compatibility SCPI
Window Numbers used to be a combination of View and Window, now the VIEW
parameter is not used and defaults to 1. All Windows are referenced through
VIEW1. For backwards compatibility the old View and Window numbers are
honored as below:
Window Old SCPI Command New SCPI Command
PVT - Burst :DISP:PVT:VIEW[1]:WIND:TRAC:X:RPOS
LEFT
:DISP:PVT:WIND[1]:TRAC:X:RPOS
LEFT
PVT – Rise :DISP:PVT:VIEW2:WIND:TRAC:X:RPOS LEFT DISP:PVT:WIND2:TRAC:X:RPOS
LEFT
PVT – Fall :DISP:PVT:VIEW2:WIND2:TRAC:X:RPOS
LEFT
DISP:PVT:WIND3:TRAC:X:RPOS
LEFT
Auto Scaling
Toggles the scale coupling function between On and Off.
Remote
Command
:DISPlay:PVTime:WINDow[1]|2|3:TRACe:X[:SCALe]:COUPle 0 | 1 | OFF | ON
:DISPlay:PVTime:WINDow[1]|2|3:TRACe:X[:SCALe]:COUPle?
Window numbers are as follows:
Burst: 1
Rise: 2
Fall: 3
Example
:DISP:PVT:WIND:TRAC:X:COUP OFF
1-Burst for Transmit On/Off Power
:DISP:PVT:WIND:TRAC:X:COUP?
1-Burst for Transmit On/Off Power
:DISP:PVT:WIND2:TRAC:X:COUP OFF
2-Rise for Transmit On/Off Power
:DISP:PVT:WIND3:TRAC:X:COUP ON
3-Fall for Transmit On/Off Power
WLAN Mode User's &Programmer's Reference 1406
