3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
All Modes show the current value of Peak-to-Average ratio on the control. However,
some Modes do not permit changing the value. In these situations, the control is
grayed-out.
Remote Command
[:SENSe]:POWer[:RF]:RANGe:PARatio <real>
[:SENSe]:POWer[:RF]:RANGe:PARatio?
Example
:POW:RANG:PAR 12 dB
Notes In some Modes, this parameter is read-only; meaning the value will appear on the control and query
via SCPI, but is not changeable. In such applications the control is grayed-out. Attempts to change the
value via SCPI are ignored, but no error message is generated
Dependencies Does not appear in Spectrum Analyzer Mode
Preset
VXT Models M9410A/11A 0dB
All Others 10dB
State Saved Saved in instrument state
Min 0dB
Max
VXT Models M9410A/11A 50dB
All Others 20dB
Mixer Lvl Offset
This is an advanced setting to adjust target Range at the input mixer, which in turn
affects the signal level in the instrument’s IF. This setting can be used when
additional optimization is needed after setting "Peak-to-Average Ratio" on page
1771. Positive values of offset optimize noise performance over distortion, negative
values optimize distortion performance over noise.
Remote Command
[:SENSe]:POWer[:RF]:RANGe:MIXer:OFFSet <real>
[:SENSe]:POWer[:RF]:RANGe:MIXer:OFFSet?
Example
:POW:RANG:MIX:OFFS -5 dB
Preset 0dB
State Saved Saved in instrument state
Min
VXT Models M9410A/11A -34dB
All Others -35dB
Max 30dB
WLAN Mode User's &Programmer's Reference 1150
