Keysight M9421A - 3.7.2.1 Stream IQ Polar

3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
View Displayed Window
EVM vs. Carrier Stream 1 EVM vs. Carrier
Stream 2 EVM vs. Carrier
EVM vs. Symbol Stream 1 EVM vs. Symbol
Stream 2 EVM vs. Symbol
Channel Matrix Channel Matrix
Stream Results Summary Stream Results Summary
Channel Results Summary Channel Results Summary
Burst & Signal Info Burst Info
Signal Info
Equalizer Impulse Response Stream 1 Channel 1 Equalizer Impulse Response
Stream 1 Channel 2 Equalizer Impulse Response
Stream 2 Channel 1 Equalizer Impulse Response
Stream 2 Channel 2 Equalizer Impulse Response
SEM Summary Channel 1 SEM
Channel 2 SEM
Spectral Flatness Stream 1 Channel 1 Spectral Flatness
Stream 2 Channel 2 Spectral Flatness
User Information Summary (11ax) User Information Summary
HE-SIG-B User Field
HE-SIG-B Common Field
User Information Summary (11be) User Information Summary
EHT-SIG User Field
EHT-SIG Common Field
User Information Summary (11ac/n) User Information Summary
3.7.2.1 Stream IQ Polar
This view has the following windows:
–
Stream X I/Q Measured Polar Graph (multiple)
–
Channel Metrics Result
–
Stream Metrics Result
Example
:DISP:EVMM:VIEW IQPM
WLAN Mode User's &Programmer's Reference 1132
