3 WLAN Mode
3.4 SEM Measurement
3.4.13.1 Abs Pwr Freq
Displays the absolute power levels in dBm and the corresponding frequencies in the
text window.
Windows: "Graph" on page 476, "Table" on page 481
Example
:DISP:SEM:VIEW APFR
3.4.13.2 Rel Pwr Freq
Displays the relative power levels in dBc and the corresponding frequencies in the
text window.
Windows: "Graph" on page 476, "Table" on page 481
Example
:DISP:SEM:VIEW RPFR
3.4.13.3 Integrated Power
Displays the absolute and relative power levels integrated throughout the
bandwidths between the start and stop frequencies in the text window.
Windows: "Graph" on page 476, "Table" on page 481
Example
:DISP:SEM:VIEW IPOW
3.4.14 Windows
There are four available window types:
–
In all Modes, the "Graph" on page 476 and "Table" on page 481 windows are
available
–
When Gate View is on, the "Gate" on page 491 window is available
This section describes the windows.
3.4.14.1 Graph
Used to display the spectrum being measured by the SEM measurement.
This window appears in several Views, as follows:
WLAN Mode User's &Programmer's Reference 476
