3 WLAN Mode
3.8 Power vs Time Measurement
[:SENSe]:RADio:STANdard[:WLAN]?
Example
:RAD:STAN AG
:RAD:STAN?
Notes If the command is sent with unsupported parameters, an error is generated “Settings conflict; option
not installed”
For IQ measurements (CCDF, Power vs Time, Spectral Flatness, IQ Waveform or Modulation Accuracy),
they are also limited by BW Option installed. when any radio standard is selected in an IQ measurement
which maximum BW could not meet this radio standard request, the “Invalid result; Wider BW required”
message will be displayed, and the measurement should return invalid data:
Enum value ACT80 means “AC Two 80MHz” (802.11ac 80+80 MHz)
Enum value AXT80 means “AX Two 80MHz” (802.11ax 80+80 MHz)
Preset
AG
State Saved Saved in instrument state
Range 802.11a/g/j/p (OFDM 20M) | 802.11b/g (DSSS/CCK/PBCC) | 802.11g (DSSS-OFDM) | 802.11n (20
MHz) | 802.11n (40 MHz) | 802.11ac (20 MHz) | 802.11ac (40 MHz) | 802.11ac (80 MHz) | 802.11ac (80
+ 80MHz)| 802.11ac (160MHz) | 802.11ah(1MHz) | 802.11ah(2MHz) | 802.11ah(4MHz) | 802.11ah
(8MHz) | 802.11ah(16MHz) | 802.11j/p (OFDM 10M) | 802.11p (OFDM 5M) | 802.11af (6MHz)|802.11af
(7Mhz) | 802.11af (8MHz) | 802.11ax (20 MHz) | 802.11ax (40 MHz) | 802.11ax (80 MHz) | 802.11ax (80 +
80MHz)| 802.11ax (160MHz) | 802.11be (20 MHz) | 802.11be (40 MHz) | 802.11be (80 MHz) | 802.11be
(160MHz)| 802.11be (320MHz)
3.8.7.3 Limits
Accesses the Limits menu that allows you to set up the test limit for channel power
or power spectral density.
Max Ramp Up Time
It used as threshold which can judge whether the real measured ramp up time can
be passed or not. If real measured ramp up time exceeds Max Ramp Up Time, then
ramp up time measurement fails, otherwise, it passes.
Remote
Command
:CALCulate:PVTime:LIMit:RUTime <time>
:CALCulate:PVTime:LIMit:RUTime?
Example
:CALC:PVT:LIM:RUT 2us
:CALC:PVT:LIM:RUT?
Preset 2.0 us
State Saved Yes
Min 0.1 us
Max 10.0 us
