3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Channel Index, Selection State, Verification State, IP Address, *IDN?
For example, “2, Selected, Verified,146.208.172.102:5025,Keysight
Technologies,N9020A,MY46471851,A.12.00_P0012”
Remote
Command
:SYSTem:COMMunicate:ANALyzer:INFormation? <address string>
Example
:SYST:COMM:ANAL:INF? “146.208.172.102:5025”
Notes The parameter of the SCPI command is the IP address and SCPI socket port number of the analyzer of
the remote analyzer list
If the parameter in an invalid IP address, for example an IP address with a wrong format or not in the list
of the remote analyzers, an error message will be generated, for example, “Invalid IP address and SCPI
socket port 0.0.0.0:0000.”
If the current analyzer is not selected, the Channel Index will be “-1”
Query All Analyzer IP Addresses (Remote Command Only)
Gets the IP addresses of all analyzers in the list of the remote analyzers.
The query result will be returned in a string containing all IP addresses and SCPI
socket port number of the analyzer in the remote analyzer list which is separated by
comma:
146.208.172.102:5125,146.208.172.102:5225,146.208.172.102:5325
Remote Command
:SYSTem:COMMunicate:ANALyzer[:IPADdress]?
Example
:SYST:COMM:ANAL?
Query remote analyzer MIMO capability (Remote Command Only)
Query the MIMO capability of the remote analyzers.
Remote
Command
:SYSTem:COMMunicate:ANALyzer:MIMO:CAPability?
Example
:SYST:COMM:ANAL:MIMO:CAP?
Notes This command is intended for VXT but be compatible to EXM
The query result will be returned in a string containing maxInputChan, maxOutputChan and Multi-box
synchronization capability separated by comma of the remote analyzer
If –MMO installed and –MTS installed, then return 8,8,1
If –MMO installed and –MTS not installed, then return 4,4,0
If –MMO not installed and –MTS installed, then return 1,1,1
If –MMO not installed and –MTS not installed, then return 1,1,0
1291 WLAN Mode User's &Programmer's Reference
