3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
NOTE
Pressing the Peak Search hardkey automatically moves you to the Peak Search
page of the Marker menu AND performs a Peak Search.
Remote
Command
:CALCulate:EVMMimo:MARKer[1]|2|…|12:MAXimum
Example
:CALC:EVMM:MARK2:MAX
:The command SYST:ERR? can be used to query the errors to determine if a peak
is found. The message “No peak found” will be returned after an unsuccessful
search
Next Peak
Pressing Next Peak moves the selected marker to the peak that is next lower in
amplitude than the current marker value. If there is no valid peak lower than the
current marker position, a “No peak found” message is generated, and the marker is
not moved.
If the selected marker was off, then it is turned on as a normal marker and a peak
search is performed.
Remote Command
:CALCulate:EVMMimo:MARKer[1]|2|…|12:MAXimum:NEXT
Example
:CALC:EVMM:MARK2:MAX:NEXT
State Saved Not saved in instrument state
Next Pk Right
Pressing Next Pk Right moves the selected marker to the nearest peak right of the
current marker that meets all enabled peak criteria. If there is no valid peak to the
right of the current marker position, a “No peak found” message is generated, and
the marker is not moved.
If the selected marker was off, then it is turned on as a normal marker and a peak
search is performed.
Remote Command
:CALCulate:EVMMimo:MARKer[1]|2|…|12:MAXimum:RIGHt
Example
:CALC:EVMM:MARK2:MAX:RIGH
Notes Sending this command selects the subopcoded marker
State Saved Not saved in instrument state
WLAN Mode User's &Programmer's Reference 1192
