3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Select RFIO Input Port Mode (Remote Command Only)
Select RFIO Input port mode.
The default value is Auto, secondary RFIO input port is following primary module
RFIO input port.
When mode is Manual, secondary RFIO input port can be set that do not follow
primary module RFIO input port
using Set RFIO Input Port (Remote Command Only)
Remote
Command
:SYSTem:COMMunicate:ANALyzer:INPut:PORT:MODE AUTO | MANual
Example
:SYST:COMM:ANAL:INP:PORT:MODE MAN
:SYST:COMM:ANAL:INP:PORT:MODE?
Notes "AUTO" means to all secondary modules RFIO port follow primary module RFIO port.
"MANual" means to every secondary module can be set RFIO port.
Preset AUTO
Range AUTO| MANual
Set RFIO Input Port (Remote Command Only)
Set module RFIO input port.
The default channel index is 1 for primary module. When channel index is 1, query
only SCPI. It returns primary
RFIO input port.
For example: :SYSTem:COMMunicate:ANALyzer:INPut:PORT:CHANnel?
The channel index 2~8 for secondary module. Set and query secondary module
RFIO input port.
For example: :SYSTem:COMMunicate:ANALyzer:INPut:PORT:CHANnel2 RFIO2
:SYSTem:COMMunicate:ANALyzer:INPut:PORT:CHANnel2?
Remote
Command
:SYSTem:COMMunicate:ANALyzer:INPut:PORT:CHANnel[1:8] RFIO1 | … | RFIO8
Example
:SYST:COMM:ANAL:INP:PORT:CHAN2 RFIO2
:SYST:COMM:ANAL:INP:PORT:CHAN2?
Notes Set specify module RFIO input port when RFIO Input Mode is set to "MANual".
Preset RFIO1
WLAN Mode User's &Programmer's Reference 1292
