Keysight M9421A - 64 QAM-2;3 RMS EVM; 64 QAM-3;4 RMS EVM

3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Preset -19.00 dB
State Saved Saved in instrument state
Min -1000
Max 0
64QAM-2/3 RMS EVM
This parameter is available when Radio Std is 802.11n, or 802.11ac.
Sets 64QAM coding rate 2/3 RMS EVM limit to warn you if the measured average
RMS EVM value exceeds a limit.
Remote
Command
:CALCulate:EVMMimo:LIMit:RMS:QA64:R2B3 <rel_ampl>
:CALCulate:EVMMimo:LIMit:RMS:QA64:R2B3
Example
:CALC:EVMM:LIM:RMS:QA64:R2B3 -20
:CALC:EVMM:LIM:RMS:QA64:R2B3?
Notes This limit value is used 802.11n, or 802.11ac
Preset -22.00 dB
State Saved Saved in instrument state
Min -1000
Max 0
64QAM-3/4 RMS EVM
This parameter is available when Radio Std is 802.11n, or 802.11ac.
Sets 64QAM coding rate ¾ RMS EVM limit to warn you if the measured average
RMS EVM value exceeds a limit.
Remote
Command
:CALCulate:EVMMimo:LIMit:RMS:QA64:R3B4 <rel_ampl>
:CALCulate:EVMMimo:LIMit:RMS:QA64:R3B4
Example
:CALC:EVMM:LIM:RMS:QA64:R3B4 -20
:CALC:EVMM:LIM:RMS:QA64:R3B4?
Notes This limit value is used 802.11n, or 802.11ac
Preset -25.00 Db
State Saved Saved in instrument state
Min -1000
Max 0
1267 WLAN Mode User's &Programmer's Reference
