3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Returned Value Burst Info Type
21 HE-SIGB
22 HE-STF
23 HE-LTF
24 HE-Data
25 EHT-USIG1
26 EHT-R-USIG1
27 EHT-USIG2
28 EHT-R-USIG2
29 EHT-SIG
30 EHT-STF
31 EHT-LTF
32 EHT-Data
Selects the MIMO Modulation Analysis measurement.
3.7.2 Views
The WLAN MIMO Modulation Analysis measurement has up to 14 views. You can
select the desired measurement view from the selections listed in the table below.
There are two available commands, allowing you to select the view using either a
string ID or a numeric ID value.
:DISP:EVMM:VIEW[:SEL] <string ID>
:DISP:EVMM:VIEW:NSEL <numeric ID>
View Name String ID Numeric ID View Description
Stream IQ Polar
IQPMimo
9 Provides a combination view of I/Q
Measured Polar Vector graph, Channel
and Stream Numeric Results data
Frequency
Response
FRMimo
10 Provides an overlay of all the individual
Stream(X) Channel(X) Frequency
Response trace data results
EVM vs. Carrier
EVCMimo
11 Provides an RMS EVM vs. Subcarrier
graph
EVM vs. Symbol
EVSMimo
12 Provides an RMS EVM vs. Symbol graph
Channel Matrix
CHMMimo
15 Provides the linear average over all
subcarriers of the Equalizer Channel
Frequency Response for each available
channel/stream
Stream Results
Summary
STSMimo
13 Provides the stream numeric summary
results
1129 WLAN Mode User's &Programmer's Reference
