3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
View Name String ID Numeric ID View Description
Channel
Results
Summary
CHSMimo
14 Provides the channel numeric summary
results
Burst & Signal
Info
BIMimo
16 Provides a summary view on Burst Info
and Signal Info
Equalizer
Impulse
Response
EIRMimo
17 Provides the equalizer impulse response
between the input stream X and input
channel X (where X is the selected
stream/channel)
SEM Summary
SEMMimo
18 Provides the SEM results for all channels
Spectral
Flatness
SFMimo
20 Provides the spectral flatness results for
all channels
User Info
Summary
(11ax)
USERinfo
23 Provides the MCS, Modulation Format,
Power, EVM and RU size for each user
User
Information
Summary
(11be)
EHTUserinfo
26 Provides the MCS, Modulation Format,
Power, EVM and RU size for each user
User
Information
Summary
(11ac/n)
VHTUserinfo
27 Provides the MCS, Modulation Format,
Power, EVM for each user
Channel Matrix is not available for SISO 802.11ax/ac 80MHz + 80MHz.
SEM Summary is only available when ‘FFT SEM Enable’ is on.
User Info Summary is only available for 802.11n/ac/ax/be.
View Selection by Name
Selects the current active view.
Remote
Command
:DISPlay:EVMMimo:VIEW[:SELect] IQPMimo | FRMimo | EVCMimo | EVSMimo | CHMMimo
| STSMimo | CHSMimo | BIMimo | EIRMimo | SEMMimo | SFMimo | USERinfo |
EHTUserinfo | VHTUserinfo
:DISPlay:EVMMimo:VIEW[:SELect]?
Example
:DISP:EVMM:VIEW IQPM
:DISP:EVMM:VIEW?
Notes SEMMimo is gray when Enable SEM is false
Preset IQPM
