3 WLAN Mode
3.12 IQ Waveform Measurement
7.
802.11be includes 802.11be 20MHz, 802.11be 40MHz, 802.11be 80MHz,
802.11be 160MHz and 802.11be 320MHz
Below each standard, parameters related to demodulation can be set, such as
Modulation Format, Guard Interval, and so on.
Remote
Command
[:SENSe]:RADio:STANdard[:WLAN] AG | BG | GDO | N20 | N40 AC20 | AC40 | AC80 |
ACT80 | AC160 | AH1 | AH2 | AH4 | AH8 | AH16 | JP10 | P5 | AF6 | AF7 | AF8 |
AX20 | AX40 | AX80 | AXT80 | AX160 | BE20 | BE40 | BE80 | BE160 | BE320
[:SENSe]:RADio:STANdard[:WLAN]?
Example
:RAD:STAN AG
:RAD:STAN?
Notes If the command is sent with unsupported parameters, an error is generated “Settings conflict; option
not installed”
For IQ measurements (CCDF, Power vs Time, Spectral Flatness, IQ Waveform or Modulation Accuracy),
they are also limited by BW Option installed. when any radio standard is selected in an IQ measurement
which maximum BW could not meet this radio standard request, the “Invalid result; Wider BW required”
message will be displayed, and the measurement should return invalid data:
Enum value ACT80 means “AC Two 80MHz” (802.11ac 80+80 MHz)
Enum value AXT80 means “AX Two 80MHz” (802.11ax 80+80 MHz)
Preset
AG
State Saved Saved in instrument state
Range 802.11a/g/j/p (OFDM 20M) | 802.11b/g (DSSS/CCK/PBCC) | 802.11g (DSSS-OFDM) | 802.11n (20
MHz) | 802.11n (40 MHz) | 802.11ac (20 MHz) | 802.11ac (40 MHz) | 802.11ac (80 MHz) | 802.11ac (80
+ 80MHz)| 802.11ac (160MHz) | 802.11ah(1MHz) | 802.11ah(2MHz) | 802.11ah(4MHz) | 802.11ah
(8MHz) | 802.11ah(16MHz) | 802.11j/p (OFDM 10M) | 802.11p (OFDM 5M) | 802.11af (6MHz)|802.11af
(7Mhz) | 802.11af (8MHz) | 802.11ax (20 MHz) | 802.11ax (40 MHz) | 802.11ax (80 MHz) | 802.11ax (80 +
80MHz)| 802.11ax (160MHz) | 802.11be (20 MHz) | 802.11be (40 MHz) | 802.11be (80 MHz) | 802.11be
(160MHz)| 802.11be (320MHz)
3.12.8.3 Advanced
Contains advanced functions that are used for specific applications. These settings
should not be changed for most measurements.
Does not appear in VXT.
Phase Noise Optimization
Sets the LO (local oscillator) phase noise behavior for various desired operating
conditions.
Remote Command
[:SENSe]:WAVeform:FREQuency:SYNThesis[:STATe] 1 | … | 5
For the meaning of each numeric option value, see "Parameter Options & Installed Options" on page
WLAN Mode User's &Programmer's Reference 1836
