3 WLAN Mode
3.6 Modulation Analysis Measurement
RU/MRU RU Size
996+[gap-242]+242+484 1726
996+242+[gap-242]+484 1727
996+484+[gap-242]+242 1728
996+484+242+[gap-242] 1729
2x996 1992
[gap-484]+484+996+996 2476
484+[gap-484]+996+996 2477
996+[gap-484]+484+996 2478
996+484+[gap-484]+996 2479
996+996+[gap-484]+484 2480
996+996+484+[gap-484] 2481
[gap-996]+996+996+996 2988
996+[gap-996]+996+996 2989
996+996+[gap-996]+996 2990
996+996+996+[gap-996] 2991
[gap-484]+484+996+996+996 3472
484+[gap-484]+996+996+996 3473
996+[gap-484]+484+996+996 3474
996+484+[gap-484]+996+996 3475
996+996+[gap-484]+484+996 3476
996+996+484+[gap-484]+996 3477
996+996+996+[gap-484]+484 3478
996+996+996+484+[gap-484] 3479
4x996 3984
‘+’ indicate this is an MRU. An MRU consists of selected combinations of multiple RUs of 26-tone RU,
52-tone RU, 106-tone RU, 242-tone RU, 484-tone RU, 996-tone RU, and 2.996-tone RU. [gap-xxx]
represents a null allocation with size xxx.
RU State
Determines the state of each RU.
Remote Command
[:SENSe]:DEMod[:WLAN]:RU:LIST:STATe OFF | ON | 0 | 1,…
[:SENSe]:DEMod[:WLAN]:RU:LIST:STATe?
Example
:DEM:RU:LIST:STAT 1,1,0,0,0,0,0,0,0
:DEM:RU:LIST:STAT?
