3 WLAN Mode
3.6 Modulation Analysis Measurement
–
If Radio Std is 802.11ah 1MHz : 2.6 Carr
–
If Radio Std is 802.11a/g/j/p (OFDM), 801.11g (DSSS-OFDM): 5.2 Carr
–
If Radio Std is 802.11n20MHz, 802.11ac 20MHz or 802.11ah 2MHz: 5.6 Carr
–
If Radio Std is 802.11n 40MHz, 802.11ac 40M or 802.11ah 4MHz: 11.6 Carr
–
If Radio Std is 802.11ac80MHz, 802.11ac 80+80MHz or 802.11ah 8MHz: 22.4 Carr
–
If Radio Std is 802.11ac160MHz or 802.11ah 16MHz: 50Carr
window 16-IQ Quadrature Skew vs. Carrier
–
If Radio Std is 802.11ah 1MHz : 2.6 Carr
–
If Radio Std is 802.11a/g/j/p (OFDM), 801.11g (DSSS-OFDM): 5.2 Carr
–
If Radio Std is 802.11n20MHz, 802.11ac 20MHz or 802.11ah 2MHz: 5.6 Carr
–
If Radio Std is 802.11n 40MHz, 802.11ac 40M or 802.11ah 4MHz: 11.6 Carr
–
If Radio Std is 802.11ac80MHz, 802.11ac 80+80MHz or 802.11ah 8MHz: 22.4 Carr
–
If Radio Std is 802.11ac160MHz or 802.11ah 16MHz: 50 Carr
window 20-Unused Tone Error
–
If Radio Std is 802.11ax/be 20MHz : 24.4 Carr
–
If Radio Std is 802.11ax/be 40MHz: 48.8 Carr
–
If Radio Std is 802.11ax/be 80MHz or 802.11ax 80+80MHz: 100.0 Carr
–
If Radio Std is 802.11ax/be 160MHz: 202.4 Carr
–
If Radio Std is 802.11be 320MHz: 407.2 Carr
5.9 ! window 22-Power vs. Symbol
State Saved Saved in instrument state
Min/Max See the table below
Window Number Min/Max
Magnitude Error 3 1.0/5000000
Phase Error 4 1.0/5000000
EVM vs. Chips 5 1.0/5000000
EVM vs. Symbol 7 0.1/2184.7
EVM vs. Carrier 8 0.1 Carriers/409.6 Carriers
Preamble Freq Error 14 0.05 us/1.0 ms
