3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
Radio Std = 802.11ah 16 MHz
[:SENSe]:DEMod[:WLAN]:AH16:GINTerval R1B4 | R1B8 | SIG | OTHer
[:SENSe]:DEMod[:WLAN]:AH16:GINTerval?
Radio Std = 802.11af 6 MHz
[:SENSe]:DEMod[:WLAN]:AF6:GINTerval R1B4 | R1B8 | SIG | OTHer
[:SENSe]:DEMod[:WLAN]:AF6:GINTerval?
Radio Std = 802.11af 7 MHz
[:SENSe]:DEMod[:WLAN]:AF7:GINTerval R1B4 | R1B8 | SIG | OTHer
[:SENSe]:DEMod[:WLAN]:AF7:GINTerval?
Radio Std = 802.11af 8 MHz
[:SENSe]:DEMod[:WLAN]:AF8:GINTerval R1B4 | R1B8 | SIG | OTHer
[:SENSe]:DEMod[:WLAN]:AF8:GINTerval?
Example Radio Std = 802.11a/g/j/p(OFDM 20 MHz)
:DEM:AG:GINT R1B4
:DEM:AG:GINT?
Radio Std = 802.11b/g(DSSS/CCK/PBCC)
:DEM:BG:GINT R1B4
:DEM:BG:GINT?
Radio Std = 802.11g(DSSS-OFDM)
:DEM:GDO:GINT R1B4
:DEM:GDO:GINT?
Radio Std = 802.11j/p(OFDM 10 MHz)
:DEM:JP10:GINT R1B4
:DEM:JP10:GINT?
Radio Std = 802.11j/p(OFDM 5 MHz)
:DEM:P5:GINT R1B4
:DEM:P5:GINT?
Radio Std = 802.11n 20 MHz
:DEM:N20:GINT R1B4
:DEM:N20:GINT?
Radio Std = 802.11n 40 MHz
:DEM:N40:GINT R1B4
:DEM:N40:GINT?
Radio Std = 802.11ac 20 MHz
:DEM:AC20:GINT R1B4
:DEM:AC20:GINT?
Radio Std = 802.11ac 40 MHz
