3 WLAN Mode
3.7 WLAN MIMO Modulation Analysis Measurement
MCS=0, MCS=1, MCS=2, MCS=3, MCS=4, MCS=5, MCS=6, MCS=7, MCS=8, MCS=9, MCS=10,
MCS=11, MCS=12, MCS=13, MCS=14, MCS = 15
Dependencies Only available for 802.11ax/be
Couplings If Modulation is 1024-QAM, limit value should be -35 dB when Track Amplitude under Sync is On and
-32 dB when Track Amplitude under Sync is Off
Preset 11ax: -5, -10, -13, -16, -19, -22, -25, -27, -30, -32, -32, -32, -38, -38, -5, -5, -10, -13
11be: -5, -10, -13, -16, -19, -22, -25, -27, -30, -32, -32, -32, -38, -38, -5, -5
State Saved Saved in instrument state
Min -1000.00
Max 0
Backwards
Compatibility SCPI
:CALCulate:EVMMimo:LIMit:RMS:AX[:LIST]:COMMon <rel_ampl>,…
:CALCulate:EVMMimo:LIMit:RMS:AX[:LIST]:COMMon?
More Information
11ax 18 elements are comma separated and defined as the following list,
corresponding to a specific MCS index and DCM state.
<rel_ampl>, ... MCS Index DCM State RMS EVM Limit Preset value (dB)
#1 0 OFF -5
#2 1 OFF -10
#3 2 OFF -13
#4 3 OFF -16
#5 4 OFF -19
#6 5 OFF -22
#7 6 OFF -25
#8 7 OFF -27
#9 8 OFF -30
#10 9 OFF -32
#11 10 OFF -35/-32
#12 11 OFF -35/-32
#13 12 OFF -38
#14 13 OFF -38
#15 0 ON -5
#16 1 ON -5
#17 3 ON -10
#18 4 ON -13
11be 16 elements are comma separated and defined as the following list,
corresponding to a specific MCS index and DCM state.
