3 WLAN Mode
3.6 Modulation Analysis Measurement
Index: n Results Returned
Returned
Value
Burst Info Type
22 B
u
r
s
t
I
n
f
o
T
y
p
e
H
E
S
T
F
23 BurstInfoTypeHELTF
24 BurstInfoTypeHEData
25 BurstInfoTypeEHTUSIG1
26 BurstInfoTypeREHTUSIG1
27 BurstInfoTypeEHTUSIG2
28 BurstInfoTypeREHTUSIG2
29 BurstInfoTypeEHTSIG
30 BurstInfoTypeEHTSTF
31 BurstInfoTypeEHTLTF
32 BurstInfoTypeEHTData
Modulation Format is defined as follows:
0 BPSK
1 QPSK
2 16QAM
3 64QAM
4 256QAM
6 1024QAM
7 4096QAM
(Please note 1024QAM is 6 instead of 5)
