3 WLAN Mode
3.6 Modulation Analysis Measurement
NOTE
Burst & Signal Info is not available for 802.11b/g (DSSS/CCK/PBCC).
NOTE
Preamble Freq Error is not available for 802.11b/g(DSSS/CCK/PBCC) and
802.11af.
NOTE
IQ Impairments is not available for 802.11a/g/j/p(OFDM), 802.11b/g
(DSSS/CCK/PBCC) and 802.11af.
NOTE
User Information Summary is only available for 802.11ax/be.
NOTE
Unused Tone Error is only available for 802.11ax/be.
NOTE
Power vs. Symbol is only available for 802.11n/ac/ax/be.
NOTE
ccEVM vs. Symbol is only available for 802.11n/ac/ax/be except 802.11ac/ax
80MHz + 80MHz
View Name String ID Numeric ID View Description
I/Q Measured
Polar Graph
POLar
1 Provides a combination view of an I/Q
Measured Polar Vector graph and the
Numeric Results data
I/Q Error
IQERror
2 Provides a combination view of a
Magnitude Error, Phase Error, EVM
window and Numeric Results for Direct
Spread Freq Modulation
OFDM EVM
OFDM
3 Provides a combination view of an RMS
EVM vs. Subcarrier graph, RMS EVM vs.
Symbol graph, I/Q Measured Polar
Vector graph, and Numeric Results
graph
Demod Bits
DBITs
4 Provides a window of demod bits
Numeric Results
NRESults
5 Provides a summary for the
measurement result and information
Burst I& Sig Info
BHTSiginfo
6 Provides a summary view on Burst Info ,
and Sig Info
Preamble freq
error
PFERror
7 Provides the total frequency error in Hz
during the preamble part of the burst
I/Q Impairments
IQIMpair
8 Provides a combination view of an IQ
