3 WLAN Mode
3.6 Modulation Analysis Measurement
Option Max Digital IF BW
B6X 600 MHz
B12 1200 MHz
Center frequency limitation:
Center Frequency Max Digital IF BW
330 MHz ~ 380 MHz (CF - 330 MHz) * 2
380 MHz ~ 550 MHz 100 MHz
550 MHz ~ 1310 MHz 200 MHz
1310 MHz ~ 2000 MHz (without Option EP6) 600 MHz
2000 MHz ~ 5480 MHz (without Option EP6) 1200 MHz
5480 MHz ~ 6080 MHz (without Option EP6) (6080 MHz - CF) * 2
1310 MHz ~ 1900 MHz (Option EP6) 600 MHz
1900 MHz ~ 6000 MHz (Option EP6) 1200 MHz
6000 MHz ~ 6600 MHz (Option EP6) (6600 MHz - CF) * 2
For VXT models M9415A/16A:
Bandwidth Option limitation:
Option Max Digital IF BW
B4X 400 MHz
B8X 800 MHz
B12 1200 MHz
Center frequency limitation:
Center Frequency Max Digital IF BW
330 MHz ~ 380 MHz (CF - 330 MHz) * 2
380 MHz ~ 550 MHz 100 MHz
550 MHz ~ 1310 MHz 200 MHz
1310 MHz ~ 2000 MHz 600 MHz
2000 MHz ~ 12300 MHz 1200 MHz
12300 MHz ~ 12900 MHz (12900 MHz - CF) * 2
M9410E/11E
Option Limitation:
Option Maximum IF BW
B40 40 MHz
B3X 300 MHz
WLAN Mode User's &Programmer's Reference 974
