Remote control commands
R&S
®
RTP
2014User Manual 1337.9952.02 ─ 12
TRIGger<m>:USB:PCONdition <OperatorPort>
Sets the operator to set a specific port number or a port number range. The port num-
ber values are set with TRIGger<m>:USB:PMIN and TRIGger<m>:USB:PMAX.
Parameters:
<OperatorPort> OFF | ANY | EQUal | NEQual | LTHan | LETHan | GTHan |
GETHan | INRange | OORange
EQUal | NEQual | LTHan | LETHan | GTHan | GETHan
Equal, Not equal, Less than, Less than or equal, Greater than,
Greater than or equal. These conditions require one port number
to be set using TRIGger<m>:USB:PMIN.
INRange | OORange
In range, out of range. These conditions require a port number
range to be set using TRIGger<m>:USB:PMIN and
TRIGger<m>:USB:PMAX.
*RST: OFF
TRIGger<m>:USB:PMIN <Port>
Specifies the port number, or sets the the start value of a port number range.
Parameters:
<Port>
TRIGger<m>:USB:PMAX <PortTo>
Sets the the end value of a port number range if TRIGger<m>:USB:PCONdition is
set to INRange or OORange.
Parameters:
<PortTo>
TRIGger<m>:USB:SCONdition <OperatorSEU>
Sets the operator to set a specific SEU or an SEU range. The SEU values are set with
TRIGger<m>:USB:SMIN and TRIGger<m>:USB:SMAX.
For SEU, see "SEU" on page 818.
Parameters:
<OperatorSEU> OFF | ANY | EQUal | NEQual | LTHan | LETHan | GTHan |
GETHan | INRange | OORange
EQUal | NEQual | LTHan | LETHan | GTHan | GETHan
Equal, Not equal, Less than, Less than or equal, Greater than,
Greater than or equal. These conditions require one SEU value
to be set using TRIGger<m>:USB:SMIN.
