Remote control commands
R&S
®
RTP
2015User Manual 1337.9952.02 ─ 12
INRange | OORange
In range, out of range. These conditions require a range of SEU
values to be set using TRIGger<m>:USB:SMIN and
TRIGger<m>:USB:SMAX.
*RST: OFF
TRIGger<m>:USB:SMIN <SEU>
Specifies the SEU, or sets the the start value of an SEU range.
Parameters:
<SEU>
TRIGger<m>:USB:SMAX
<SEUTo>
Sets the the end value of an SEU range if TRIGger<m>:USB:SCONdition is set to
INRange or OORange.
Parameters:
<SEUTo>
TRIGger<m>:USB:SPEC <USBSpecialType>
Sets the trigger to one out of four different Special PID types: PREamble, ERR, SPLit,
or PING.
Parameters:
<USBSpecialType> PREamble | ERR | SPLit | PING
PREamble
Sets the trigger to the PREamble PID
ERR
Sets the trigger to the ERRor PID
SPLit
Sets the trigger to the SPLIT PID (in USB high speed transac-
tions)
PING
Sets the trigger to the PING PID (in USB high speed transac-
tions, flow control probe for a bulk/control endpoint)
*RST:
PREamble
TRIGger<m>:USB:STCO <SC>
Sets the trigger to a specific start-split or complete-split transaction endpoint.
Parameters:
<SC> ONE | ZERO | DC
ONE
SC = 1 represents a complete-split (CSPLIT) transaction.
