RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
970
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 3D
As of scan system firmware  206x.
Only intelliWELD:
Flags sensor board
Value range with 16-bit protocol: [0…65,535].
Value range with 20-bit protocol: [0…65,535].
16-bit
protocol
20-bit
protocol
Bit #15
(MSB)
Bit #19
(MSB)
= 1: Protective-window temperature value not in
[0…1,882].
Bit #14 Bit #18
= 1: Temperature of mirror 1 value not in
[0…2,250].
Bit #13 Bit #17 = 1: Temperature of mirror 2 value not in
[0…2,250].
Bit #10 Bit #14
= 1: Emerging-beam-opening temperature value not in
[0…1,200]. Additionally, an INTERLOCK error is
initiated.
Bit #3 Bit #7
= 1: Protective-window scattered light value not in
[0…2,250].
Bit #2 Bit #6 = 1: Coolant-flow rate value not in
[750…2,250].
Bit #1 Bit #5
= 1: Galvanometer-mount temperature value not in
[0…1,600]. Additionally, an INTERLOCK error is
initiated.
Bit #0 Bit #4
= 1: Collimator temperature value not in
[0…2,000]. Additionally, an INTERLOCK error is
initiated.
– Bit #0
…
Bit #3
= 0.
…
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
