RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
976
Code
HIGH
(hex)
11
As of scan system firmware 2078.
SelectControlDefinition
Only scan systems equipped with several tunings (or corresponding servo algorithms).
SelectControlDefinition causes the scan systems to switch to a certain tuning.
See also Chapter 8.1.4 ”Selecting the Tuning (Dynamics Setting)”, page 216.
Code
LOW
= 00…03
specifies the tuning number.
As of scan system firmware 5050.
Only excelliSCAN:
excelliSCAN scan heads do not support SelectControlDefinition. With excelliSCAN scan heads,
there is only one tuning.
Code
LOW
(hex)
00 Tuning 0 (= default setting)
01 Tuning 1
02 Tuning 2
03 Tuning 3
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
